Iridescent Yellow Zinc Plated Steel Brake Line Tube – Galvanized Brake Pipe

[vc_row rt_row_background_width=”default” rt_row_style=”default-style” rt_row_borders=”” rt_row_paddings=”true” rt_bg_effect=”classic” rt_bg_image_repeat=”repeat” rt_bg_size=”cover” rt_bg_position=”right top” rt_bg_attachment=”scroll” rt_bg_video_format=”self-hosted”][vc_column rt_wrp_col_paddings=”false” rt_border_top=”” rt_border_bottom=”” rt_border_left=”” rt_border_right=”” rt_border_top_mobile=”” rt_border_bottom_mobile=”” rt_border_left_mobile=”” rt_border_right_mobile=”” rt_bg_image_repeat=”repeat” rt_bg_size=”auto auto” rt_bg_position=”right top” rt_bg_attachment=”scroll”][vc_column_text]

Tube

  • ASTM A254/SAE J527 double wall brazed steel tube:
  • Mechanical Properties:
    • Tensile strength: 290MPa min.
    • Yield strength: 180MPa min.
    • Elongation: 20% min.
  • Tube OD: 3.18mm – 15mm.
  • Tube wall thickness: 0.7mm, 0.9mm, 1mm.

Zinc Plating (Galvanizing)

  • Coating thickness: 8μm – 25μm.
  • Neutral salt spray test: 72 hr – 140 hr before red rust.
  • Appearance: yellow, iridescent.
  • ROHS: Cr+6(hexavalent chromium) free.

Packaging

  • Continuous coils, uncut on pallet.
  • Straight cut, in wooden/steel box.
  • Small coils cut, on pallet or in wooden/steel box.
